The vanilla RNNs suffer from vanishing and exploding gradients, which makes them difficult to train on long sequences.
LSTM (Long Short-Term Memory) networks were introduced to address these issues by introducing a more complex architecture that can learn long-term dependencies.
Architecture
At each time step \(t\) , an LSTM unit processes the current input \(x_t\) , the previous hidden state \(h_{t−1}\) , and the previous cell state \(C_{t-1}\) to produce a new hidden state \(h_t\) and cell state \(C_t\) .
1.Forget Gate : Decides what information to discard from the cell state.
\[f_t = \sigma(W_{xf} x_t + W_{hf} h_{t-1} + b_{f})\]
2.Input Gate : Decides what new information to add to the cell state.
\[i_t = \sigma(W_{xi} x_t + W_{hi} h_{t-1} + b_{i}) \\ \tilde{C}_t = tanh(W_{xC} x_t + W_{hC} h_{t-1} + b_C) \]
3.Output Gate : Decides what information to output based on the cell state.
\[o_t = \sigma(W_{xo} x_t + W_{ho} h_{t-1} + b_o)\]
4.Cell State : The memory of the LSTM that carries long-term information.
\[C_t = f_t * C_{t-1} + i_t * \tilde{C}_t\]
5.Hidden State : The output of the LSTM cell at the current time step.
\[h_t = o_t * \tanh(C_t)\]
Training
The goal is to minimize a loss function (e.g., cross-entropy, MSE) by updating the weights of the LSTM using gradient descent and backpropagation through time (BPTT).
BPTT is similar to RNNs but accounts for the cell state and gates in LSTMs.
Backward Pass
Input: \(d\_out = \frac{dL}{dh_t}\) from the next layer or loss function.
Gradients w.r.t \(W_{xf}\) :
\[\begin{align*}
\frac{\partial L}{\partial W_{xf}} &= \frac{\partial L}{\partial f_t} \cdot \frac{\partial f_t}{\partial W_{xf}} \\
&= \frac{\partial L}{\partial C_t} \cdot \frac{\partial C_t}{\partial f_t} \cdot \frac{\partial f_t}{\partial a_f} \frac{\partial a_f}{\partial W_{xf}} \\
&= \frac{\partial L}{\partial C_t} \cdot C_{t-1} \cdot f_t (1 - f_t) \cdot (x_t)^T
\end{align*}\]
\(\frac{\partial L}{\partial C_t}\) , this gradient arise from 2 sources:\(h_t\) .\(C_{t+1}\) depends on \(C_t\) via the forget gate.
\[\begin{align*}
\frac{\partial L}{\partial C_t} &= \frac{\partial L}{\partial h_t} \frac{\partial h_t}{\partial C_t} + \frac{\partial L}{\partial C_{t+1}} \frac{\partial C_{t+1}}{\partial C_t} \\
&= \frac{\partial L}{\partial h_t} \cdot o_t \cdot (1 - \tanh^2(C_t)) + \frac{\partial L}{\partial C_{t+1}} \cdot f_{t+1}
\end{align*}\]
Gradients w.r.t \(W_{xi}, W_{hf}, W_{hi}\) can be derived similarly.
Gradients w.r.t \(W_{xC}\)
\[\begin{align*}
\frac{\partial L}{\partial W_{xC}} &= \frac{\partial L}{\partial \tilde{C}_t} \cdot \frac{\partial \tilde{C}_t}{\partial W_{xC}} \\
&= \frac{\partial L}{\partial C_t} \cdot \frac{\partial C_t}{\partial \tilde{C}_t} \frac{\partial \tilde{C}_t}{\partial W_{xc}} \\
&= \frac{\partial L}{\partial C_t} \cdot i_t \cdot (1 - \tilde{C}_t^2) \cdot (x_t)^T
\end{align*}\]
Gradients w.r.t \(W_{hC}\) can be derived similarly.
Gradients w.r.t \(W_{xo}\) :
\[\begin{align*}
\frac{\partial L}{\partial W_{xo}} &= \frac{\partial L}{\partial o_t} \cdot \frac{\partial o_t}{\partial W_{xo}} \\
&= \frac{\partial L}{\partial h_t} \cdot \frac{\partial h_t}{\partial o_t} \cdot \frac{\partial o_t}{\partial a_o} \frac{\partial a_o}{\partial W_{xo}} \\
&= \frac{\partial L}{\partial h_t} \cdot \tanh(C_t) \cdot o_t (1 - o_t) \cdot (x_t)^T
\end{align*}\]
Gradients w.r.t \(W_{ho}\) can be derived similarly.
Gradients w.r.t input (\(x_t ~\&~ h_{t-1}\) )
\[\begin{align*}
\frac{\partial L}{\partial x_t} &= \frac{\partial L}{\partial f_t} \cdot \frac{\partial f_t}{\partial x_t} + \frac{\partial L}{\partial i_t} \cdot \frac{\partial i_t}{\partial x_t} + \frac{\partial L}{\partial o_t} \cdot \frac{\partial o_t}{\partial x_t} + \frac{\partial L}{\partial \tilde{C}_t} \cdot \frac{\partial \tilde{C}_t}{\partial x_t} \\
&= \frac{\partial L}{\partial f_t} \cdot f_t (1 - f_t) \cdot W_{xf} + \frac{\partial L}{\partial i_t} \cdot i_t (1 - i_t) \cdot W_{xi} + \frac{\partial L}{\partial o_t} \cdot o_t (1 - o_t) \cdot W_{xo} + \frac{\partial L}{\partial \tilde{C}_t} \cdot (1 - \tilde{C}_t^2) \cdot W_{xC}
\end{align*}\]
\(dx_t\) is required if we are also training the layers before the LSTM layer, such as an embedding layer or a convolutional layer.
\[\begin{align*}
\frac{\partial L}{\partial h_{t-1}} &= \frac{\partial L}{\partial f_t} \cdot \frac{\partial f_t}{\partial h_{t-1}} + \frac{\partial L}{\partial i_t} \cdot \frac{\partial i_t}{\partial h_{t-1}} + \frac{\partial L}{\partial o_t} \cdot \frac{\partial o_t}{\partial h_{t-1}} + \frac{\partial L}{\partial \tilde{C}_t} \cdot \frac{\partial \tilde{C}_t}{\partial h_{t-1}} \\
&= \frac{\partial L}{\partial f_t} \cdot f_t (1 - f_t) \cdot W_{hf} + \frac{\partial L}{\partial i_t} \cdot i_t (1 - i_t) \cdot W_{hi} + \frac{\partial L}{\partial o_t} \cdot o_t (1 - o_t) \cdot W_{ho} + \frac{\partial L}{\partial C_t} \cdot (1 - \tilde{C}_t^2) \cdot W_{hC}
\end{align*}\]
\(dh_{t-1}\) is sent back to the previous time step.
Vanishing Gradients
In LSTMS the recursive part is \(\frac{\partial L}{\partial C_t} \propto \frac{\partial L}{\partial C_{t+1}} * f_{t+1}\)
\(\frac{\partial L}{\partial C_{t+1}} * f_{t+1} = \frac{\partial L}{\partial C_{t+2}} * f_{t+2} * f_{t+1} = \frac{\partial L}{\partial C_{T}} \cdot \Pi_{j=1}^{T-t} f_{t+j}\)
Variants of LSTM
Bidirectional LSTM : Processes the sequence in both forward and backward directions, allowing the model to capture context from both past and future.Stacked LSTM : Stacks multiple LSTM layers to increase model capacity and capture more complex patterns.Peephole Connections : Allows the gates to access the cell state directly, improving performance on certain tasks.GRU (Gated Recurrent Unit) : A simplified version of LSTM with fewer parameters, combining the forget and input gates into a single update gate.
